There are some major tools, the iPhone Face ID dot projector programmer and dot matrix flex cable, so you can test and program the iPhone dot projector and replace the dot matrix flex cable. There are also tools to help fix the iPhone Face ID issues.
1. Dot projector programmer
Before we are going to fix the iPhone Face ID, we need to use a dot projector programmer to test the iPhone dot projector, so that we can roughly judge the face ID problem. Meanwhile, we can use dot projector programmers to program the dot matrix flex cable. The following models are currently common in the market for hot sales.
- JC V1S dot projector board (recommend)
JC V1S dot projector board is produced by JCID factory, this is a very experienced and quality manufacturer. JC V1S dot projector board needs to be used with the JC V1S host, and it supports the iPhone X-12 Pro Max. This board is small and light, easy to carry, and affordable.
- JC Lattice dot projector module (recommend)
JC lattice dot projector module is also produced by JCID factory, now the 2ND Gen model has been released, it supports the iPhone X-12 Pro Max. JC lattice dot projector module needs to be used with the JC Pro1000s host, it's affordable.
- I2C V8i programmer (recommend)
I2C V8 programmer can be used alone, it is a stand-alone programmer that does not need to be used with other devices, now it supports the iPhone X-11 Pro Max (it will be supported for iPhone 12 series soon). I2C V8 programmer is easy to use, and cost-effective.
- Magico iFace Tool programmer
Magico iFace Tool programmer can be used alone, it is a stand-alone programmer that does not need to be used with other devices, now it supports the iPhone X-11 Pro Max.
- LUBAN iFace Pro programmer
LUBAN iFace Pro programmer can be used alone, it is a stand-alone programmer that does not need to be used with other devices, now it supports the iPhone X-11 Pro Max.
- Qianli ID FACE programmer
Qianli ID FACE programmer can be used alone, it is a stand-alone programmer that does not need to be used with other devices, now it supports the iPhone X-11 Pro Max.
2. Dot Matrix flex cable/IC
When you are going to repair iPhone Face ID, you may need to replace the iPhone face ID dot matrix flex cable or IC.
- JC dot matrix flex cable (recommend)
JC dot matrix flex cable is for JCID products, it can be used for JC V1S dot projector board and JC lattice dot projector module. JC dot matrix flex cable supports the iPhone X-12 PRO MAX, high quality, stable performance and reasonable price, it's very popular in the market.
- I2C V8 dot matrix flex cable (recommend)
I2C V8 dot matrix flex cable is for I2C V8 programmer, it supports the iPhone X-11 PRO MAX for now, high quality, stable performance and reasonable price.
- Magico dot matrix flex cable
Magico dot matrix flex cable is for Magico iFace Tool programmer, it supports the iPhone X-11 PRO MAX for now.
- LUBAN dot matrix flex cable
LUBAN dot matrix flex cable is for LUBAN iFace Pro programmer, it supports the iPhone X-11 PRO MAX for now.
- Luban lattice chip module board
Luban lattice chip module board is for the LUBAN iFace Pro programmer, it supports the iPhone X-11 PRO MAX for now.
- Qianli dot matrix flex cable
Qianli dot matrix flex cable is for Qianli ID FACE programmer, it supports the iPhone X-11 PRO MAX for now.
3. Dot matrix fixture
When you are going to repair or replace iPhone Face ID problems, you need a fixture to fix the dot projector or flex cable, or calibrating the position of the flex cable.
- Qianli DZJ1 dot projector fixture (recommend)
- Qianli Dot Projector Calibrator (x-11 pro max) (recommend)
- MaAnt MR-01 Face lattice fixture (recommend)
- WL dot projector fixture
- AIXUN Dot projector fixture
- MJ K33 fixture
- Luban D1 fixture
- Luban T1 fixture
4. Dot matrix reballing stencil
When you are going to replace the dot matrix flex cable, you may do some reballing work, so you need special Face ID repair BGA reballing stencil.
- Mechanic reballing stencil (recommend)
- WYLIE WL-02 Stencil
- WL dot matrix stencil
- MIJING IPH-14 stencil
- MaAnt BGA Reballing Stencil
5. Blade kit/solder paste
When you are going to repair the iPhone Face ID, you need some tools to remove the glue on the face ID parts, and some special glue and solder paste to repair the iPhone Face ID.
- Mechanic Dot Matrix Repair Set(recommend)
- BGA blade graver kit
- Dot Matrix Repair Blade Set (recommend)
